In many different industries, stainless steel 304/316 cast pipe fittings are used to connect, terminate, control flow, and alter piping direction.
|
Product Name |
Stainless Steel Female Tees |
|
Material |
Stainless Steel S/s 304,316,304l,316l,430,409 Etc. Carbon Steel And Certain Alloy Steel. |
|
Size |
1/8''-4'' |
|
Dn6, Dn6, Dn8, Dn10, Dn15, Dn20, Dn25, Dn32, Dn40, Dn50, Dn65, Dn80, Dn100. |
|
|
Thread |
Npt, Din2999, Bsp, Bspt, Bspp, Pt,pf |
|
Pressure |
150 Lbs |
|
Surface Threatment |
Polished,sand Blast |
|
Standard |
Iso9001:2008, Ce, Ped 97/23/ec |
|
Main Products |
Elbow45.,90.,street Elbow,tee,cross,hex Nipple,red Socket M/f,plug,socket Banded,hex Cap,round Cap, |
|
Nut, Bushing,union, Coupling, Spe, Spu,hose Nipple, Welding Nipple, Barrel Nipple, Parrel Nipple |
|
|
Amr,auto Parts,sanitary Union,sanitary Fitting,sanitary Valve |
|
|
Technics |
Investment Casting / Seamless Pipe Machining |
|
Technology |
Silica Colloidal Solution craft |
|
Dimension conform to |
ISO4144, SP114, EN-10241, JIS |
|
Sample Making |
Available, Free sample with freight collect |
|
Package |
Plastic bag,bubble bag, cartons, wooden pallet,wooden box |
|
Custom |
Available, customize as your design,photo,drawing |
|
Payment terms |
30% prepayment T/T,balance against B/L; L/C. |
|
after-service |
Replacement for free if there is any quality problem |
|
Lead time |
Usually no more than 30 days, according to your quantity |
Different design for different requirements,Pressure 150LBs conform to ISO 4144, SP 114, EN-10241, LIGHT TYPE .
The thread with NPT ,ISO7-1 ,ISO228.
Screw fitting are available from 1/8" to 4", in Grade CF8M (SS316), CF8 (SS304), DIN
1.4408, DIN 1.4308 stainless steel ASTM A351.
Production Capacities :
casting capacity is 80Ton /month ; Machining capacity is 100Ton /month
1.6 production size range :1/8"-4" product name :ELBOW 90,TEE, CROSS, STREET ELBOW 90 , WELDING NIPPLE ,BARREL NIPPLE ,REUDCING SOCKET ,HEX BUSHING , UNION , SOCKET etc .
Production process:
Raw material--Chemical Tes--Mould Making--Wax Injection--Reparing Burr--Assembly--Sand-Shell Making--Dewaxing--Chemical test before pouring--Pouring--Knockout--Cutting--Grinding--Shot Blasting--Acid Washing--Process Inspection--Machining--Robot Machining--Cleaning--Pressure--Assembling--Final Inspection--Package
FAQ:
Q:Are units that failed inspection clearly marked and separated to prevent accidental dispatch?
A:Yes, the units are separated and marked clearly
Q:How are finished products that failed inspection handled?
A:Thrown away
Q:Does the company provide ODM service for others?
A:Yes
