Pipe Size:DN15-DN200
Standard：ANSI BS DIN
Material：304&316&304L&316L
Working pressure:200PSI/PN16
SPECIFICATION:
Working Pressure : 800 PSI WOG
Temperature : -20 ~ 232'C
Suitable Medium : Water, Oil, Air & Some Corrosive Liquid
Thread Kind : NPT, BSPT, BSP, DIN259/2999
|
SIZE |
A |
H |
L |
|
1/2" |
15 |
42 |
65 |
|
3/4" |
20 |
51 |
80 |
|
1" |
25 |
60 |
90 |
|
1-1/4" |
32 |
67 |
105 |
|
1-1/2" |
40 |
75 |
120 |
|
2" |
50 |
81 |
140 |
|
2-1/2" |
65 |
93 |
180 |
|
3" |
80 |
104 |
200 |
■(WIN-VIET PRECISION MACHINERY COMPANY LTD ) WIN-VIET is establised in 2018 , a subsidiary company of KH Group. It is about 60km(1.5hour by car) far away from Ho Chi Minh City . Production Process is silicasol precision Lost Waxing technology in stainless steel material, Product Range is 150LB screwed fittings , auto parts, valves and Hardware parts,etc Covering 25000㎡,construction area of 15000㎡
Casting ability:80ton /month .
Product requirements are strict：
Internal:test raw material of stainless steel and wax;
repair WAX ,if the wax mold is unqualified, the cluster process will not be assembled.\4
Before pouring, spectrum analysis will be carried out
After passivation, the first casting inspection will be carried out. If it is unqualified, it will be returned for treatment.
We have three inspection teams when processing CNC lathes, namely, workers' self inspection, patrol inspection and final inspection before leaving the factory. Even, some products will be leak tested.
Due to so carefully to quality,we win more and more returned customers.
External:Passed ISO,BV, PED,AD2000,UKCA,accept any 3rd party inspection before shipment.
Product requirements are strict：
Raw material--Chemical Tes--Mould Making--Wax Injection--Reparing Burr--Assembly--Sand-Shell Making--Dewaxing--Chemical test before pouring--Pouring--Knockout--Cutting--Grinding--Shot Blasting--Acid Washing--Process Inspection--Machining--Robot Machining--Cleaning--Pressure--Assembling--Final Inspection--Package
FAQ：
Q: How long is your delivery time?
A: Generally it is 10 days if the goods are in stock. or it is 100 days if the goods are not in stock, it is according to quantity.
Q:Are units that failed inspection clearly marked and separated to prevent accidental dispatch?
A:Yes, the units are separated and marked clearly
Q:How are finished products that failed inspection handled?
A:Thrown away
Q:Does the company provide ODM service for others?
A:Yes
